[#PETALSBCREST-64] Unable to declare operations on a resource mapped on several service providers - Petals Link JIRA

Details

Type: Improvement Request
Status: Open
Priority: Major
Resolution: Unresolved
Affects Version/s: 1.1.1-BC
Fix Version/s: None
Component/s: Consumer mode
Security Level: Public

Description:

Hide

I have a business resource for which operations (create, update, list, ...) are distributed over several services. I use the following configuration:

<jbi:jbi ...>
   <jbi:services binding-component="true">
      <jbi:consumes interface-name="inscription-cantine:inscriptionCantine">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="inscription-cantine:new">
               <rest:http-method>POST</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine</rest:path-template>
               ...
            </rest:operation>
            <rest:operation name="inscription-cantine:validate">
               <rest:http-method>PUT</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine/{numero-demande}</rest:path-template>
               ...
            </rest:operation>
         </rest:mapping>
      </jbi:consumes>

      <jbi:consumes interface-name="flowable-integration:Task">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="flowable-integration:getTasks">
               <rest:http-method>GET</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine?statut='En attente'</rest:path-template>
               ...
         </rest:mapping>
      </jbi:consumes>

      <jbi:consumes interface-name="flowable-integration:ProcessInstances">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="flowable-integration:getProcessInstances">
               <rest:http-method>GET</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine?usager-demandeur={usager-demandeur}</rest:path-template>
               ...
            </rest:operation>
         </rest:mapping>
      </jbi:consumes>
   </jbi:services>
</jbi:jbi>

When deploying it, I get the following error:

org.ow2.petals.component.framework.api.exception.PEtALSCDKException: A Servlet has been already added with the service base path '/api'
	at org.ow2.petals.binding.rest.exchange.incoming.RESTServer.addRESTService(RESTServer.java:124)
	at org.ow2.petals.binding.rest.RESTComponent.addRESTService(RESTComponent.java:98)
	at org.ow2.petals.binding.rest.RESTSUManager.doDeploy(RESTSUManager.java:70)
	at org.ow2.petals.component.framework.su.AbstractServiceUnitManager.deploy(AbstractServiceUnitManager.java:144)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeploySUToComponentTask.deploySUtoComponent(DeploySUToComponentTask.java:119)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeploySUToComponentTask.execute(DeploySUToComponentTask.java:73)
	at org.ow2.petals.microkernel.api.jbi.management.TaskProcessor.process(TaskProcessor.java:73)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.registerAndDeploySU(DeployAllSUTask.java:156)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.deploySUS(DeployAllSUTask.java:119)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.execute(DeployAllSUTask.java:78)
	at org.ow2.petals.microkernel.api.jbi.management.TaskProcessor.process(TaskProcessor.java:73)
	at org.ow2.petals.microkernel.jbi.management.deployment.DeploymentServiceImpl.deploy(DeploymentServiceImpl.java:166)

Show

I have a business resource for which operations (create, update, list, ...) are distributed over several services. I use the following configuration:

<jbi:jbi ...>
   <jbi:services binding-component="true">
      <jbi:consumes interface-name="inscription-cantine:inscriptionCantine">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="inscription-cantine:new">
               <rest:http-method>POST</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine</rest:path-template>
               ...
            </rest:operation>
            <rest:operation name="inscription-cantine:validate">
               <rest:http-method>PUT</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine/{numero-demande}</rest:path-template>
               ...
            </rest:operation>
         </rest:mapping>
      </jbi:consumes>

      <jbi:consumes interface-name="flowable-integration:Task">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="flowable-integration:getTasks">
               <rest:http-method>GET</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine?statut='En attente'</rest:path-template>
               ...
         </rest:mapping>
      </jbi:consumes>

      <jbi:consumes interface-name="flowable-integration:ProcessInstances">
         <cdk:timeout>${municipalite.timeout.clt-services.qf}</cdk:timeout>
         <cdk:mep xsi:nil="true" />
         <rest:service-base-path>/api</rest:service-base-path>
         <rest:mapping>
            <rest:operation name="flowable-integration:getProcessInstances">
               <rest:http-method>GET</rest:http-method>
               <rest:path-template>/demarches-administratives/demande-cantine?usager-demandeur={usager-demandeur}</rest:path-template>
               ...
            </rest:operation>
         </rest:mapping>
      </jbi:consumes>
   </jbi:services>
</jbi:jbi>

When deploying it, I get the following error:

org.ow2.petals.component.framework.api.exception.PEtALSCDKException: A Servlet has been already added with the service base path '/api'
	at org.ow2.petals.binding.rest.exchange.incoming.RESTServer.addRESTService(RESTServer.java:124)
	at org.ow2.petals.binding.rest.RESTComponent.addRESTService(RESTComponent.java:98)
	at org.ow2.petals.binding.rest.RESTSUManager.doDeploy(RESTSUManager.java:70)
	at org.ow2.petals.component.framework.su.AbstractServiceUnitManager.deploy(AbstractServiceUnitManager.java:144)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeploySUToComponentTask.deploySUtoComponent(DeploySUToComponentTask.java:119)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeploySUToComponentTask.execute(DeploySUToComponentTask.java:73)
	at org.ow2.petals.microkernel.api.jbi.management.TaskProcessor.process(TaskProcessor.java:73)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.registerAndDeploySU(DeployAllSUTask.java:156)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.deploySUS(DeployAllSUTask.java:119)
	at org.ow2.petals.microkernel.jbi.management.task.deployment.deploy.DeployAllSUTask.execute(DeployAllSUTask.java:78)
	at org.ow2.petals.microkernel.api.jbi.management.TaskProcessor.process(TaskProcessor.java:73)
	at org.ow2.petals.microkernel.jbi.management.deployment.DeploymentServiceImpl.deploy(DeploymentServiceImpl.java:166)

Environment:

-

Activity

Ascending order - Click to sort in descending order

Hide

Permalink

Christophe DENEUX added a comment - Wed, 4 Apr 2018 - 10:11:56 +0200

With the first section 'consumes' a servlet is created. A check prohibit to create another servlet with the same base path.

Instead of creating a second servlet, the first one should be updated with configuration of other operations

Show

Christophe DENEUX added a comment - Wed, 4 Apr 2018 - 10:11:56 +0200 With the first section 'consumes' a servlet is created. A check prohibit to create another servlet with the same base path. Instead of creating a second servlet, the first one should be updated with configuration of other operations
